Solar Window Film Carbon Film HP Series

With excellent product quality and perfect sales service system, Kashibang products are not only sold well throughout the country, but also exported to 34 countries and regions such as Southeast Asia, the Middle East, Europe and the United States, and are deeply trusted by customers.

Model
HP70	HP35	HP15
HP05	HP03

Carbon Film

Product Features

Medium Insulation
5G Film, Without Affecting The Signal

More Information of Product

Model：HP70

Visible Light Transmittance : 70%

IR Heat Rejected (950nm) : 29%

IR Heat Rejected (1400nm) : 26%

Ultraviolet Rejected : 99%

Total Solar Energy Rejection : 33%

Total Solar Transmittance : 0.67

Internal Reflectance : 08%

Shading Coefficient : 0.75

Haze : 0.95

Scratch Resistance : 3H

Thickness: 1.5 mil

Color Decay Time (years) : 3 years

Model：HP35

Visible Light Transmittance : 35%

IR Heat Rejected (950nm) : 42%

IR Heat Rejected (1400nm) : 35%

Ultraviolet Rejected : 99%

Total Solar Energy Rejection : 63%

Total Solar Transmittance : 0.37

Internal Reflectance : 08%

Shading Coefficient : 0.41

Haze : 1.40

Scratch Resistance : 3H

Thickness: 1.5 mil

Color Decay Time (years) : 3 years

Model：HP15

Visible Light Transmittance : 15%

IR Heat Rejected (950nm) : 60%

IR Heat Rejected (1400nm) : 50%

Ultraviolet Rejected : 99%

Total Solar Energy Rejection : 73%

Total Solar Transmittance : 0.27

Internal Reflectance : 08%

Shading Coefficient : 0.30

Haze : 1.52

Scratch Resistance : 3H

Thickness: 1.5 mil

Color Decay Time (years) : 3 years

Model：HP05

Visible Light Transmittance : 05%

IR Heat Rejected (950nm) : 72%

IR Heat Rejected (1400nm) : 62%

Ultraviolet Rejected : 99%

Total Solar Energy Rejection : 84%

Total Solar Transmittance : 0.16

Internal Reflectance : 08%

Shading Coefficient : 0.18

Haze : 1.52

Scratch Resistance : 3H

Thickness: 1.5 mil

Color Decay Time (years) : 3 years

Model：HP03

Visible Light Transmittance : 03%

IR Heat Rejected (950nm) : 73%

IR Heat Rejected (1400nm) : 62%

Ultraviolet Rejected : 99%

Total Solar Energy Rejection : 86%

Total Solar Transmittance : 0.14

Internal Reflectance : 08%

Shading Coefficient : 0.15

Haze : 1.73

Scratch Resistance : 3H

Thickness: 1.5 mil

Color Decay Time (years) : 3 years

Note: The above data is laboratory test data, only represents the performance of the test sample batch, and is not used for specification parameters to determine the actual product parameters. Different tester, there may be some Tolerance.
